WDBR-IV Accuracy 0.2 Transformer Capacity and No-Load Tester

$1500.00

Model

Basic info Product Detail Supplier

Basic info

Brand	Wone
Model NO.	WDBR-IV Accuracy 0.2 Transformer Capacity and No-Load Tester
Output Voltage	0～10V
Output current	0～10A
Series	WDBR-IV

Product Detail

Description

This instrument is a multi-function measuring instrument, which is equivalent to the usual two kinds of test instruments: the active transformer capacity tester and the transformer characteristic parameter tester. In the characteristic test, it can be tested by the traditional two-meter method or the standard three-wire four-wire tester. The phase system test can not only compare the parameters with the traditional test method, but also accurately measure the parameters. It can accurately measure a series of power frequency parameters such as capacity, type, no-load current, no-load loss, load loss, impedance voltage, etc. of various transformers. The accuracy of capacity and characteristic test results is 100%. The capacity measurement range: 10kVA~100000kVA.

Specifications

Interal power output range
Voltage	0～10V
Current	0～10A
Characteristic test power input range
Voltage	0～750V
Current	0～100A
Test accuracy
Voltage, current	±0.2%
Power	±0.5% (CosΦ>0.1), ±1.0% (0.02<CosΦ<0.1)
Working temperature	-20℃～+60℃
Charger power requirements	Mains AC160V～265V
Insulation degree
(1)The insulation resistance of the capacity test, voltage and current input points to the chassis is greater than or equal to 100MΩ
(2) The charging power input to the chassis is subjected to a power frequency of 2KV (effective value), and the test time is 1 minute.
Volume	32cm×24cm×13cm
Weight	2.5㎏
