Description ：

YB series products is a kind of set of  equipment which assembles the MV switch  apparatus, transformer, LV distribution  equipment together according to fixed  connection scheme. This series substation is  suitable for neighborhood unit, hotel, large-scale  work site and high building that the voltage is  12kV /24kV/36kV/40.5kV, the frequency is  50Hz and the capacity is under 2500kvA.

Main Designation Characteristics :

• The crust of the substation is designed according to the foreign advanced technology and  physical reality. We provide many kinds of crust material such as aluminum alloy steel  composite stainless steel board and non metal material(glass fiber).

• The HV side use charge switch or vacuum circuit breaker. The transformer could be oil  type hermetically-sealed type and dry type.

• The proof of the box is double layers structure and between the layers is filled with foam.  There are independent boards in HV and LV room, and in the transformer room will install  auto thermal controller heater and cooling equipment.

Note: we offer special customized products according to client’s requirement.

Service environment:

• Air temperature: Maximum temperature: +40℃; Minimum temperature:-25℃；

• Humidity: Monthly average humidity 95%; Daily average humidity 90%；

• Altitude above sea level: Maximum installation altitude: 2500m；

• Ambient air not apparently polluted by corrosive and flammable gas, vapor etc；

• No frequent violent shake.

Main technical specifications:

12/24/36kV

40.5kV

Main Primacy Wiring Circuit Schemas for Substation(40.5kV):

Wiring type A-40.5kV:

Wiring type B-40.5kV:

Note: we offer special customized products according to client’s requirement.

Wiring type C -40.5kV:

Wiring type D -40.5kV:

Note: we offer special customized products according to client's requirement.

What is a prefabricated substation?

A:A prefabricated substation is an electrical substation with pre - assembled components in factory, featuring modular design, easy combination via standardized interfaces, and wide - ranging scenario adaptability.

What is a package substation?

A: A package substation is a prefabricated, all - in - one unit integrating high - voltage equipment, transformers and low - voltage devices, used to transform and distribute electricity efficiently.
