  • KGC-1189Desktop Dissolved Gas Analysis Analyzer
KGC-1189Desktop Dissolved Gas Analysis Analyzer
discuss personally
Model
KGC-1189
Basic info Product Detail Supplier
Basic info
Brand ROCKWILL
Model NO. KGC-1189Desktop Dissolved Gas Analysis Analyzer
Signal output digits 24 Bit
Temperature control accuracy of column box ± 0.02℃
Display accuracy 0.01℃
Series KGC
Product Detail

Overview：

The KGC-1189  Desktop Dissolved Gas Analysis Analyzer（DGA） is suitable for the determination of the content of dissolved gas components in the insulating oil of the power system. With a single injection, it can complete a comprehensive analysis of the contents of seven gas components dissolved in the insulating oil, namely hydrogen (H₂), carbon monoxide (CO), carbon dioxide (CO₂), methane (CH₄), ethylene (C₂H₄), ethane (C₂H₆), and acetylene (C₂H₂). Its minimum detection concentration for acetylene can reach 0.1 ppm.

Main feature:

  • Built - in remote control technology for intuitive display of instrument gas path pressure

  • Remote control technology for temperature setting and display operations of the instrument

  • Remote control technology for one - key startup

  • Computer remote control to complete operations such as ignition and current setting with a click

  • Digital FID electronic zero - adjustment technology to enhance the instrument's anti - interference ability

  • Thermal conductivity tungsten filament protection function against gas interruption

Technology parameters:


Gas path process :


Schematic diagram:

Schematic diagram of hydrogen flame ionization detector (FID)


Structural diagram of hydrogen flame ionization detector (FID)
